class: center, middle, inverse, title-slide .title[ # Marine Community Ecology 2024 ] .subtitle[ ## 04-Simulating ecological processes ] .author[ ### Simon J. Brandl ] .institute[ ### The University of Texas at Austin ] .date[ ### 2024/01/01 (updated: 2024-02-26) ] --- background-image: url("images/IMG_2352.jpg") background-size: cover class: center, top, inverse # Simulating ecological processes <style type="text/css"> .scrollable { height: 300px; overflow-y: auto; } .scrollable-auto { height: 75%; overflow-y: auto; } .remark-slide-scaler { overflow-y: auto; } </style> --- ## Loops - Loops in R are an efficient way to perform repeated actions over a defined sequence - They follow a basic syntax that always starts with 'for', have a variable that denotes each iteration (usually denoted as a single letter), and are enclosed by curly brackets ```r library(tidyverse) # load tidyverse package - you'll need it later ``` ``` ## ── Attaching core tidyverse packages ──────────────────────── tidyverse 2.0.0 ── ## ✔ dplyr 1.1.4 ✔ readr 2.1.4 ## ✔ forcats 1.0.0 ✔ stringr 1.5.1 ## ✔ ggplot2 3.4.4 ✔ tibble 3.2.1 ## ✔ lubridate 1.9.3 ✔ tidyr 1.3.0 ## ✔ purrr 1.0.2 ## ── Conflicts ────────────────────────────────────────── tidyverse_conflicts() ── ## ✖ dplyr::filter() masks stats::filter() ## ✖ dplyr::lag() masks stats::lag() ## ℹ Use the conflicted package (<http://conflicted.r-lib.org/>) to force all conflicts to become errors ``` ```r for (i in 1:8) { print(i) } ``` ``` ## [1] 1 ## [1] 2 ## [1] 3 ## [1] 4 ## [1] 5 ## [1] 6 ## [1] 7 ## [1] 8 ``` - pretty simple, but also not the most useful loop --- ### More useful loops - Oftentimes, you will use for loops to iterate over an existing list or dataframe - Just as often, you will actually want to store the output of your for loop in a new object - Below we are creating abundance data for five different birds over ten years ```r bird.list <- c("shearwater", # create a list of four different marine birds "albatross", "penguin", "booby") num.years <- 10 # create a vector that contains the number of years lambdas <- c(10, 20, 30, 20) # create values for different poisson distributions bird.target.data <- matrix(ncol = length(bird.list), # create an output matrix w nrow = num.years) colnames(bird.target.data) <- bird.list # name columns for (i in 1:length(bird.list)) { # initiate loop with i over the number of birds x <- rpois(10, lambdas[i]) # draw 10 values from the poisson with lambda i bird.target.data[,i] <- x # fill target dataset at position i with x } bird.target.data ``` ``` ## shearwater albatross penguin booby ## [1,] 7 16 30 17 ## [2,] 8 20 23 21 ## [3,] 4 18 26 20 ## [4,] 12 24 34 20 ## [5,] 10 18 26 15 ## [6,] 11 25 33 23 ## [7,] 8 17 30 13 ## [8,] 8 19 32 20 ## [9,] 14 24 35 20 ## [10,] 7 22 32 23 ``` --- # Numerical modeling .pull-left[ - Great tool to understand the complex and dynamic nature of ecological processes - Often involve time-stepping simulations to explore dynamics over time - Applicable to all species in any ecosystem, including Daisyworld (Lovelock 1992, Phil Trans Roy Soc) ] .pull-right[ <img src="images/daisyworld.png" width="100%" /> ] --- class: center ## The Moran Model 🤓 ### A neutral, closed community with no evolutionary forces Initial community of *J individuals* divided among *S species* 🐠 🐡 &darr; Select one individual at random to die 💀 &darr; Select one individual at random to reproduce, replacing the casualty 🐣 &darr; Rinse and repeat 🚿 --- ### Running the model - this code was adapted from [Vellend 2016: A Theory of Ecological Communities](https://press.princeton.edu/books/hardcover/9780691164847/the-theory-of-ecological-communities-mpb-57) ```r num.sims <- 20 # specify the number of simulations num.years <- 50 # specify the number of years freq.1.mat <- matrix(ncol = num.sims, nrow = num.years) # create a matrix for output # FIRST LOOP FOR DIFFERENT SIMULATIONS for (j in 1:num.sims) { # use for-loop to run through the number of simulations J <- 100 # 100 individuals t0.sp1 <- 0.5*J # abundance of species 1 at time 0 community <- vector(length = J) # set up community community[1:t0.sp1] <- 1 # specify that half of the community is species 1 community[(t0.sp1+1):J] <- 2 # specify the other half is species 2 year <- 2 # set 'year' to 2 freq.1.mat[1,j] <- sum(community==1)/J # fill community matrix # SECOND LOOP FOR INDIVIDUAL DEATH/BIRTH for (i in 1:(J*(num.years-1))) { # second for-loop to run multiple simulations freq.1 <- sum(community==1)/J # freq.1 represents the frequency of species 1 pr.1 <- freq.1 # pr.1 represents the frequency of reproduction community[ceiling(J*runif(1))] <- sample(c(1,2), 1, prob=c(pr.1,1-pr.1)) # birth and death rates, based on probabilities if (i %% J == 0) { # record data in the freq.1.mat matrix freq.1.mat[year, j] <- sum(community==1)/J year <- year + 1 } } } colnames(freq.1.mat) <- 1:num.sims # set column names in matrix freq.sp1.df <- as.data.frame(freq.1.mat) %>% # convert freq.1.mat into data frame add_column(year = 1:num.years) # add a column called year ``` --- ### Model output - let's take a look at the output of our model ```r head(freq.sp1.df) ``` ``` ## 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 ## 1 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 ## 2 0.49 0.54 0.61 0.37 0.49 0.39 0.52 0.53 0.55 0.53 0.51 0.52 0.47 0.47 0.59 ## 3 0.57 0.67 0.49 0.40 0.43 0.44 0.59 0.59 0.56 0.47 0.52 0.43 0.62 0.44 0.61 ## 4 0.60 0.66 0.53 0.44 0.41 0.48 0.59 0.52 0.67 0.38 0.52 0.39 0.55 0.42 0.63 ## 5 0.47 0.82 0.63 0.36 0.57 0.56 0.64 0.44 0.73 0.46 0.57 0.32 0.47 0.36 0.71 ## 6 0.40 0.92 0.51 0.37 0.45 0.54 0.62 0.43 0.78 0.60 0.58 0.39 0.55 0.29 0.71 ## 16 17 18 19 20 year ## 1 0.50 0.50 0.50 0.50 0.50 1 ## 2 0.48 0.42 0.44 0.59 0.66 2 ## 3 0.59 0.44 0.41 0.63 0.60 3 ## 4 0.58 0.51 0.54 0.67 0.56 4 ## 5 0.73 0.66 0.56 0.56 0.64 5 ## 6 0.75 0.69 0.54 0.46 0.60 6 ``` - beautiful data, but we'll have to gather it if we want it to be tidy --- ### Processing and visualizing the model outputs .pull-left[ - we can use our acquired skills in tidy data wrangling and ggplot to turn the model outputs into pretty plots ```r freq.sp1.proc <- freq.sp1.df %>% gather(1:20, key = iteration, value = frequency) p1 <- ggplot(freq.sp1.proc, aes(x = year, y = frequency, group = iteration)) + geom_line(aes(color = frequency), alpha = 0.8) + scale_color_gradient(low = "darkorchid", high = "goldenrod") + theme_bw() + theme(legend.position = "none") + scale_y_continuous(limits = c(0,1)) + xlab("Years") + ylab("Frequency of species 1") ``` ] .pull-right[ .center[ <!-- --> ]] --- ### Changing model parameters - let's change the number of individuals to _1000_ and the number of years to _100_ ```r num.sims <- 20 num.years <- 100 # change number of years freq.1.mat <- matrix(ncol = num.sims, nrow = num.years) # create a matrix for output for (j in 1:num.sims) { J <- 1000 # change to 1000 individuals t0.sp1 <- 0.5*J community <- vector(length = J) community[1:t0.sp1] <- 1 community[(t0.sp1+1):J] <- 2 year <- 2 freq.1.mat[1,j] <- sum(community==1)/J for (i in 1:(J*(num.years-1))) { freq.1 <- sum(community==1)/J pr.1 <- freq.1 community[ceiling(J*runif(1))] <- sample(c(1,2), 1, prob=c(pr.1,1-pr.1)) if (i %% J == 0) { freq.1.mat[year, j] <- sum(community==1)/J year <- year + 1 } } } ``` --- ### Model results - let's see what this produced .pull-left[ ```r colnames(freq.1.mat) <- 1:num.sims freq.sp1.df <- as.data.frame(freq.1.mat) %>% add_column(year = 1:num.years) freq.sp1.proc <- freq.sp1.df %>% gather(1:20, key = iteration, value = frequency) p1 <- ggplot(freq.sp1.proc, aes(x = year, y = frequency, group = iteration)) + geom_line(aes(color = frequency), alpha = 0.8) + scale_color_gradient(low = "darkorchid", high = "goldenrod") + theme_bw() + theme(legend.position = "none") + scale_y_continuous(limits = c(0,1)) + xlab("Years") + ylab("Frequency of species 1") ``` ] .pull-right[ .center[ <!-- --> ]] --- class: center, middle <img src="images/butterfly_meme.jpeg" width="60%" /> --- class: center, middle # The end
